ZAH-392H – Shock Reduced Air Hammer
Professional-Grade Pneumatic Hammer with Advanced Vibration Control
The ZAH-392H Shock Reduced Air Hammer is a high-performance air tool engineered for industrial, automotive, and construction applications. Designed to deliver powerful impact while reducing operator fatigue, this air hammer ensures precision, efficiency, and long-lasting durability for demanding tasks.
Key Features
Advanced Shock Reduction – Minimizes vibration and recoil, providing enhanced operator comfort and reducing strain during prolonged use.
High-Impact Performance – Delivers consistent, strong blows for chipping, cutting, and heavy-duty material removal.
Robust Construction – Built with premium materials for longevity in tough work environments.
Ergonomic Design – Optimized grip and balance for better control and precise operation.
Wide Chisel Compatibility – Supports a range of pneumatic chisels and attachments for versatile applications.
Smooth Pneumatic Operation – Ensures stable, reliable performance in continuous use.
Technical Specifications
Model: ZAH-392H
Type: Shock Reduced Air Hammer
Power Source: Compressed Air
Impact Frequency: High-speed pneumatic operation
Recommended Applications: Chipping, cutting, demolition, surface preparation, metal shaping
Benefits
Minimized Operator Fatigue – Shock reduction technology reduces strain on hands and arms.
Enhanced Efficiency – Consistent, high-speed hammering accelerates heavy-duty work.
Durable Design – Engineered to withstand industrial and construction environments.
Precision Handling – Ergonomic design for better control and accuracy.
Versatile Applications – Ideal for automotive, metalworking, construction, and maintenance tasks.
Applications
Construction & Demolition: Chipping concrete, masonry, and other harsh surfaces.
Automotive & Bodywork: Rust removal, cutting welds, and metal trimming.
Industrial Maintenance: Surface preparation and repair work.
Metalworking & Fabrication: Precision chiseling and shaping.
Why Choose the ZAH-392H?
The ZAH-392H Shock Reduced Air Hammer is engineered to combine power, comfort, and durability. Its advanced vibration-reduction system ensures safer, more comfortable operation, making it an essential tool for professionals who demand high performance in industrial, automotive, and construction settings.
Features
- Designed with the following patents to ensure the best shock reduction and operator’s comfort.
1) Portable pneumatic tool assembled with module units.
2) Suspension vibration-reducing means for portable pneumatic tools. - Alloy steel-made impact parts are heat-treated for durability.
- Quick-Change Retainer for Simple Accessory Changes.
- Ergonomic handle with a rubber-made exhaust muffler for added operator comfort.
- An optional patented universal swivel air inlet joint for the best maneuverability of the tool.
- Bumper
- Air inlet tube
- Valve seat
- Air actuating valve
- Auxiliary damping spring
- Ergonomic handle with rubber sleeve
Specification:
- Chisel Shank Opening: 0.410(10.4) inch(mm)
- Bore Diameter: 3/4(19) inch(mm)
- Stroke Length: 1-31/32(50) inch(mm)
- Blows Per Minute: 4000 bpm
- Avg. Air Cons.: 15.2(430) cfm(l/min)
- Net Weight: 3.4(1.5) lbs(kgs)
- Air Inlet Size: 1/4 PT/NPT
- Operating Air Pressure: 90(6.2) PSI(bar)
- Min. Hose Size: 3/8(10) inch(mm)
- Vibration: 2.5 m/s2
ZAH-392HK
Accessories
- Shock-Reduced Air Hammer X 1
- 192913 Retainer Spring
- CH641RL 7″ Single End Cutter X 1
CH645RL 7″ Cut Off Chisel X 1
CH649RL 7″ Rivet Cutter Chisel X 1
CH672RL 7″ Special Panel Cutter X 1
CH627RL 7″ Shear Chisel X 1
| Model | Chisel Shank Opening inch(mm) | Bore Diameter inch(mm) | Stroke Length inch(mm) | Blow Per Minch bpm | Avg. Air Cons cfm(l/min) | Net Weight lbs(kgs) | Minch Hose Size inch(mm) | Vibration m/s² |
| ZAH-392 | 0.401(10.2) | 3/4(19) | 1-31/32(50) | 4000 | 15.2(430) | 3.4(1.5) | 3/8(10) | 2.5 |
| ZAH-392H | 0.410(10.4) | 3/4(19) | 1-31/32(50) | 4000 | 15.2(430) | 3.4(1.5) | 3/8(10) | 2.5 |
| ZAH-393 | 0.401(10.2) | 3/4(19) | 2-5/8(66) | 3000 | 4.95(140) | 4(1.8) | 3/8(10) | 10 |
| ZAH-393H | 0.410(10.4) | 3/4(19) | 2-5/8(66) | 3000 | 4.95(140) | 4(1.8) | 3/8(10) | 10 |
| ZAH-394 | 0.401(10.2) | 3/4(19) | 3-1/2(89) | 2100 | 5.65(160) | 4.6(2.1) | 3/8(10) | 5.5 |
| ZAH-394H | 0.410(10.4) | 3/4(19) | 3-1/2(89) | 2100 | 5.65(160) | 4.6(2.1) | 3/8(10) | 5.5 |
| ZAH-592 | 0.401(10.2) | 3/4(19) | 1-31/32(50) | 4000 | 15.2(430) | 3.4(1.5) | 3/8(10) | 2.5 |
| ZAH-592H | 0.410(10.4) | 3/4(19) | 1-31/32(50) | 4000 | 15.2(430) | 3.4(1.5) | 3/8(10) | 2.5 |
| ZAH-593 | 0.401(10.2) | 3/4(19) | 2-5/8(66) | 3000 | 4.95(140) | 4(1.8) | 3/8(10) | 10 |
| ZAH-593H | 0.410(10.4) | 3/4(19) | 2-5/8(66) | 3000 | 4.95(140) | 4(1.8) | 3/8(10) | 10 |
| ZAH-594 | 0.401(10.2) | 3/4(19) | 3-1/2(89) | 2100 | 5.65(160) | 4.6(2.1) | 3/8(10) | 5.5 |
| ZAH-594H | 0.410(10.4) | 3/4(19) | 3-1/2(89) | 2100 | 5.65(160) | 4.6(2.1) | 3/8(10) | 5.5 |
| ZNS-392 | 0.401(10.2) | 3/4(19) | 1-31/32(50) | 4000 | 15.2(430) | 3.4(1.5) | 3/8(10) | 2.5 |
| ZCH-394B | 0.401(10.2) | 3/4(19) | 3-1/2(89) | 2100 | 6(170) | 4.6(2.1) | 3/8(10) | 5.3 |
*(H)-Chisel Shank Opening 0.410″(10.4mm) *Operating Air Pressure: 90psi/6.2bar. *Air Inlet Size: 1/4″ PT/NPT
