ZS312M Air Pipe Saw-Metal Housing
Features
- Designed with following patents to assure extreme low vibration and operator’s comfort.
1)Portable pneumatic tool assembled with module units in clam shell composite housing.
2)Suspension vibration-reducing means for portable pneumatic tools. - Engineering plastic made clam-shell housing designed for easy service.
- Patented universal swivel air inlet joint for the best maneuverability of the tool.
- Safety trigger to prevent accidental start ups and provide operator’s comfort.
- Rear exhaust directs air away from work-piece.
- Adjustable Saw Blade Guard
- Tool Less Saw Blade Holder
- Suspension Damping Spring
- Operating Module
- Air Actuating Module
- Air Inlet Module
- Safety Trigger
- Rear Exhaust
- Clam-shell composite housing
Specification:
- Blows Per Minute: 10000 bpm
- Stroke Length: 10 mm
- Avg. Air Cons.: 7.6(215) cfm(l/min)
- Net Weight: 1.0(0.45) lbs(kgs)
- Air Inlet Size: 1/4 inch-NPT/PT
- Min. Hose Size: 3/8(10) inch(mm)
- Vibration: 4.3 m/s2
- Sound Pressure: 80.4 dB(A)
ZS312MK
Kit include:
- Bi-metal blades
18T X 5
24T X 5
32T X 5
For ZS311, ZS311M, ZS315, ZS319, ZS319H, ZS319-T2R, ZS319-T2B
COMPARISON CHART WITH COMPETITIVE DESIGNS IS AVAILABLE UPON REQUEST.
Model | Blow Per Min bpm | Stroke Length mm | Avg. Air Cons. cfm(l/min) | Net Weight lbs(kgs) | Air Inlet Size inch-NPT/PT | Minch Hose Size inch(mm) | Vibration m/s² | Sound Pressure dB(A) |
ZS319-T2B | 9500 | 10 | 3(90) | 1.17(0.53) | 1/4 | 3/8(10) | 3.7 | 85 |
ZS311M | 10000 | 10 | 7.6(215) | 1.0(0.45) | 1/4 | 3/8(10) | 4.3 | 80.4 |
ZS312M | 10000 | 10 | 7.6(215) | 1.0(0.45) | 1/4 | 3/8(10) | 4.3 | 80.4 |
ZS317M | 5800 | 20 | 6.9(195) | 1.17(0.53) | 1/4 | 3/8(10) | 8.4 | 81.5 |
*Operating Air Pressure: 90psi/6.2bar
